一款采用晶晨S905X2处理器的硬盘播放器，支持4K硬解码，支持内置2.5寸硬盘，支持samba协议，可作为NAS使用。S905X2是晶晨的新一代家庭影音SoC，采用12纳米的制程工艺，集成四颗A53架构的的处理器核心，图形处理器采用Dvalin MP2，支持4GB运行内存。目前产品运行的是安卓8.1开放系统，后续会升级到安卓9.0系统，S905X2也是业内首批将支持安卓9.0系统的主控芯片。
此款安卓播放器已经量产，多个配置可选，我们专业从事方案运作，可根据用户需求定制产品，可提供硬件设计和软件开发的整套服务。
| System hardware configuration: | ||||||
| Type | Details | Descriptions | ||||
| CPU | Type | Amlogic S905X2 Quad-core Cortex-A53 12nm | ||||
| GPU | Type | ARM Dvalin MP2 GPU support OpenGL ES3.2/OpenCL2.0 |
||||
| RAM | Capacity | 4GB(Custom 2G) | ||||
| ROM | EMMC | 32GB/64GB/128GB(Option) | ||||
| Network Connections: | ||||||
| Type | Details | Descriptions | ||||
| WIFI | WIFI module | 2T2R IEEE 802.11 a/b/g/n/ac（2.4G&5G） Support 20MHz/40MHz/80MHz 300Mbps in 802.11n,876Mbps in 802.11 ac |
||||
| Bluetooth | V4.2 Support 4.2+HS,BLE,ANT and compatible with v1.2,2.X | |||||
| Ethernet Network | RJ45 | IEEE 802.3 10/100M/1000M | ||||
| Interface Configuration: | ||||||
| Type | Details | Descriptions | ||||
| Memory card socket | External memory | SDHC/SDXC Support 4GB/8GB/16GB/32GB/64GB | ||||
| USB interface | Data transfer supportive | USB2.0x1 USB3.0x3 | ||||
| AV jack | AV output | ∮3.5mm jack CVBS 480i/576i standard definition output | ||||
| DC connector | Power | ∮5.5mm jack | ||||
| HDMI interface | Audio/Video output | HDMI 2.1 ,4Kx2K@75 max resolution output. Support transmitter with 3D,, Dynamic HDR ,CEC and HDCP 2.2 |
||||
| SATA jack | Data transfer supportive | support2.5〃HDD 500G/1T/2T(Power consumption<4W) | ||||
| S/PDIF jack | Audio output | S/PDIF OUT | ||||
| Software Configuration: | ||||||
| 系统版本 | Android 8.1 | |||||
| VIDEO | Amlogic Video Engine (AVE) with dedicated hardware decoders and encoders – Support multi-video decoder up to 4Kx2K@60fps+1x1080P@60fps – Supports multiple “secured” video decoding sessions and simultaneous decoding and encoding – Video/Picture Decoding – VP9 Profile-2 up to 4Kx2K@60fps – H.265 HEVC MP-10@L5.1 up to 4Kx2K@60fps – AVS2-P2 Profile up to 4Kx2K@60fps – H.264 AVC HP@L5.1 up to 4Kx2K@30fps – H.264 MVC up to 1080P@60fps – MPEG-4 ASP@L5 up to 1080P@60fps (ISO-14496) – WMV/VC-1 SP/MP/AP up to 1080P@60fps – AVS-P16(AVS+) /AVS-P2 JiZhun Profile up to 1080P@60fps – MPEG-2 MP/HL up to 1080P@60fps (ISO-13818) – MPEG-1 MP/HL up to 1080P@60fps (ISO-11172) – RealVideo 8/9/10 up to 1080P@60fps – Multiple language and multiple format sub-title video support – MJPEG and JPEG unlimited pixel resolution decoding (ISO/IEC-10918) – Supports JPEG thumbnail, scaling, rotation and transition effects – Supports *.mkv,*.wmv,*.mpg, *.mpeg, *.dat, *.avi, *.mov, *.iso, *.mp4, *.rm and *.jpg file formats Video/Picture Encoding Independent JPEG and H.265/H.264 encorder with configurable performance/bit-rate JPEG image encording H.265/H.264 video encording up to 1080P@60fps with latency |
|||||
| AUDIO | Supports MP3, AAC, WMA, RM, FLAC, Ogg and programmable with 7.1/5.1 down-mixing Built-in serial digital audio SPDIF/IEC958 input/output and PCM input/output built-in TDM/PCM/I2S ports with TDM/PCM mode up to 384kHz x32bits x 8ch or 96kHz x 32bits x 32ch and I2S mode up to 384kHz x 32bits x 8ch |
|||||
| Image | HD JPEG、BMP、GIF、PNG、TIF | |||||
| Language | English French German Spanish Italian etc multilateral languages | |||||
