一款采用瑞芯微RK3399芯片方案的智能视频会议一体机，标准版运行安卓10操作系统，可自由安装卸载软件，兼容主流的软件视频会议系统。采用高度集成的一体化设计，内置4K摄像头和10米拾音的阵列麦克风，可快速搭建视频会议系统。可为行业客户提供安卓11和Linux系统调试。
| Hardware /Software | ||
| System | OS | Android 10 |
| OS Upgradable | OTA | |
| Application Processor | RK3399 Dual Cortex A72，Quad Cortex A53 2GHZ | |
| CPU Clock Rates | Max 2GHz | |
| SDRAM | 4GB DDR3 | |
| Internal Storage | 32GB EMMC | |
| RTC function | Yes | |
| Additional Storage | 2G to 32G | |
| Wireless transmission | Wi-Fi | Dual 802.11a/b/g/n/ac 2.4GHZ and 5GHZ |
| Bluetooth | B/T4.1 | |
| NFC | NO | |
| Zigbee | NO | |
| 2.4G remote | Yes | |
| Audio | Speaker | 8ohm 3W×2 |
| AEC | XMOS with 2*2 digital microphone，-26dBm sensitivity 10 meters voice recongnition |
|
| Camera | Sensor | Sony IMX274, 1/2.5inch, 8 Mega pixels |
| Lens | 4 Glass + 2 plastic Lens, 112degree FOV, f=1.8 | |
| IR cut | 2 filter | |
| IR LED | 1W *4 | |
| Tilting | 2 motors with 20 degress rotate for 4 directions | |
| Sound | microphone | four omni-directional microphones supporting 10 m diameter range |
| Yes | ||
| Light sensor | Yes | |
| Extended Interface | DC-in | 5V 2A |
| USB Type A | Host * 1 | |
| USB Type C | USB3.0 | |
| RJ45 | 1000Mbps | |
| HDMI | Yes | |
| MicroSD card Slot | 2G to 32G | |
| COM | Debugging | |
| LED | RGB LED | 24 RBG LEDs on the ring |
| Mute LED | Microphone and Camera mute LED | |
| Climatic Requirements |
Storage Temp. | -20℃~60℃ |
| Storage Humidity | 5 to 90%RH | |
| Operating Temp. | 0℃~50℃ | |
| Operating Humidity | 20~85%RH | |
