一款面向外贸市场的高性价比智能网络机顶盒，采用Amlogic S905W2芯片方案，集成四核A35 CPU和 G31图形处理器。运行开放的安卓11操作系统，内置双频WiFi模块和蓝牙模块，支持4K视频解码和输出。此款网络机顶盒支持定制，可为客户提供一站式产品定制服务，支持OEM和ODM订单。
| Basic parameters Amlogic Android 11 S905W2 OTT BOX | ||||
| CPU | Chipset | S905W2 | ||
| Architecture | Quad Core ARM Cortex A35 | |||
| GPU | Chipset | Mali-G31 MP2 | ||
| Architecture | OpenGL ES 1.1/2.0/3.2，OpenCL 2.0，Vulkan 1.1 support | |||
| RAM | Capacity | 2GB (1/2GB Optional) | ||
| ROM | Capacity | 16GB (8/16GB Optional) | ||
| External storage | USB Storage Devices | Supported | ||
| Micro SD card | Supported | |||
| Software | ||||
| Operating system | OS Version | Android 11 | ||
| Language | Multi-Language | |||
| Multimedia | Video | Video Decoder: | ||
| AV1 MP-10@L5.1 up to 4Kx2K@60fps | ||||
| VP9 Profile-2 up to 4Kx2K@60fps | ||||
| H.265 HEVC MP-10@L5.1 up to 4Kx2K@60fps | ||||
| H.264 AVC HP@L5.1 up to 4Kx2K@30fps | ||||
| MPEG-4 ASP@L5 up to 1080P@60fps (ISO-14496) | ||||
| WMV/VC-1 SP/MP/AP up to 1080P@60fps | ||||
| AVS-P16(AVS+) /AVS-P2 JiZhun Profile up to 1080P@60fps | ||||
| MPEG-2 MP/HL up to 1080P@60fps (ISO-13818) | ||||
| MPEG-1 MP/HL up to 1080P@60fps (ISO-11172) | ||||
| Supports JPEG thumbnail, scaling, rotation and transition effects | ||||
| Multiple language and multiple format sub-title video support | ||||
| Supports *.mkv,*.wmv,*.mpg, *.mpeg, *.dat, *.avi, *.mov, *.iso, *.mp4, *.rm and *.jpg file formats | ||||
| Audio | Supports MP3, AAC, WMA, RM, FLAC | |||
| Image | HD JPEG、BMP、GIF、PNG、TIF | |||
| Network service | ||||
| Wi-Fi | Type | Option Support WiFi: IEEE 802.11 b / g / n or IEEE 802.11 a/b/g/n/ac | ||
| Frequency | Option:2.4G &5G | |||
| Antenna Type | Inside antennas | |||
| Bluetooth | Bluetooth | Option | ||
| Interface | ||||
| Charge | DC connector | DC IN(5V/2A) | ||
| Video output | HDMI | 4K*2K UHD Output, HDMI 2.1 | ||
| Micro SD | External memory | Support | ||
| USB port | USB host | 2*USB 2.0 | ||
| Ethernet | Ethernet | 100M Ethernet | ||
| Appearance | ||||
| Body Material | Plastic | |||
| Color | Black | |||
| Size | 77X77X16(mm) | |||
| Weight | 0.090Kg | |||
| Cerifications(For Unit) | ||||
| Standard | CE | / | ||
| RoHS | / | |||
| Others | Optional | / | ||
| Package contents | Shipping Info | |||
| User manual | *1 | Gift Box Dimension(mm) | 155x100x55mm | |
| Gift Box | *1 | Carton Size(mm) | 570x315x172MM | |
| Remote control | *1 | Qty Per Carton(pcs) | 40PCS | |
| HD external cable | *1 | Gift Box.G.W(gs) | 0.298Kg | |
| Power adapter | *1 | Export carton (G.W.)(kgs) | 12.9Kg | |
